BLACKDOG MAX DEEP COILS

The search coils for Blackdog metal detectors are compatible with the detector models of the main brands on the market. The Blackdog coils have been designed to considerably increase the depth and area of ​​search for objects in places where objects have previously been searched for with standard coils included in the detectors of the different brands on the market.

BLACKDOG MAX COIL 33 x 33cm DD

High impact ABS plastic with UV treatment. – Copper winding with 99% purity, for greater electrical conductivity. The quality of the winding is very important to achieve a greater «Q» factor, which translates into a greater magnetic field and greater depth of the detector. The cable used is made to measure, internally covered by a shield of 99% of its total surface. It also has a textile fiber reinforcement, to prevent it from splitting when it is exposed to pulls. The resin used is of the Epoxy type with UV protection and a very high glass transition coefficient (TG), to withstand high temperatures without losing its properties.

osciloscopio blackdogcoils
Our resin withstands temperatures above 120 degrees. A post-curing process is applied to all our coils in a special oven, so that the resin maintains its characteristics regardless of the temperature changes to which the coils are subjected. Our coils are adjusted one by one manually, using oscilloscopes and laboratory tools, to get the most out of our products.

banner plato blackdog max

SPECIFICATIONS

  1. Double D coil, for better discrimination and more precise target location.
  2. Better penetration in mineralized ground or under ceramics.
  3. More stability, allowing to increase the sensitivity of the detector.
  4. The coils include double shielding of low capacitance graphite, eliminating electrical interference, false signals in wet terrain, wet grass, rubbing against plants or wet sandy beaches.
  5. Fully submersible and waterproof dish
  6. Depth increase of up to 70% compared to standard coils, depending on the type of detector.
  7. Includes coils protector.
  8. The winding may vary depending on the detector model.
caracteristicas blackdog max
plato blackdog max imagen de calidad
plato detector de metales blackdog max general

MARCAS COMPATIBLES

FISHER
F5, F11, F19, F22, F44, F70, F75. F75SE, F75LTD
F70, F75.
Gold Bug, Gold Bug Pro,

GARRETT
Ace 150/250/350/Euro, Ace 200/300/400
AT Pro
AT Gold
AT Max
Apex
TEKNETICS
Eurotek
Eurotek Pro
Digitek
Omega/Gamma/Delta/Alpha, G2,G2+,T2,T2+,T2 SE, T2-LTD
QUEST
Q20, Q40
Quest X5, Quest X10, Quest X30, Quest Q30+
Quest X10 Pro
WHITES
MX5, M6, MXT, DFX
Spectra VX3, V3, V3i
Coinmaster, Prizm Series
Trasure Master, Treasure Master Pro
NOKTA MARKO
Racer, Racer 2
Kruzer, Multikruzer, Anfibio, Anfibio Multi, Nokta impact, Fors Core

CE quality certificate
